Background

I'm pretty interested in voice llm applications, I've tried to build a simple talking bot connected to llm right before chat gpt released their voice mode (not the advanced one with realtime-api, the classic one). I've also attended OpenAI's real-time api and reasoning hackathon, we built a working prototype, but it's just a proof of concept and I find it hard to see the path to productize such audio AI agent.

Luckily, when I attended the 2025 AI engineer summit the very next week, I stumbled upon Daily.co's booth at the expo. I've been using daily.co in my day job for a while. And I noticed they are all in on AI audio agents more recently. Their logo also appeared on Jensen Huang's CES keynote, in the AI orchestration and management section. I had a chance to chat with their CEO Kwindla, I asked about their pipecat framework, his take on speech-to-speech vs classic, and some technical stuff like turn taking. Later I figured they already have a primer about voice AI, so I read it and took some notes.

My top takeaways

• Things are moving fast, and phone applications are the fast growing use case
• Latency is very important in voice agent, web RTC can handle a lot of things, but still need to always keep in mentioned
• Function calling, async process can have some quirks, but it's critical to building agents
• Some eval is better than no eval, and audio have different kind of ways
• Will start exloring with pipecat to build some side project

Notes

Chapter 1,2

Conversational AI is happening and moving at a fast pace, the guide is written by the Pipecat team. Pipecat is a vendor-neutral agent layer, widely used by different teams and companies. So they are very familiar with all the details.

Chapter 3: Conversational AI

Basic Conversational AI Loop Voice capture -> STT -> LLM -> TTS -> Play audio

Chapter 4: Core Technology and Best Practices

4.1 Latency

• Very important, will be mentioned in many places, because human expect fast response with audio.
• Manually measure latency between voice and voice is easy.
• But hard to do programmatically, because of all the layers. time-to-first-(audio)-byte is used as a proxy and 800ms is a good target.

4.2 LLM for Voice Use Case

Starting with GPT-4, it seems possible because:

• Low latency
• LLM can follow instructions
• Function calling
• Low hallucination
• Can have personality
• Cost is reasonable

And currently stoa model can do pretty well:

• 4o (4o-mini is not faster)
• Sonnet 3.5 (TTFT slower than others)
• Gemini 2.0 (10x cheaper)

Adding context, it’s not so easy to pin cost/min
Open models are potentially possible with recent developments

Speech-to-speech

• Lower latency
• Understand nuances
• Natural voice

But:

• Latency actually is higher since audio has more token
• Understanding nuances doesn’t have real benefit now
• Weird behavior in voice model
• APIs are still work in progress

4.3 Speech to Text

• TTS Deepgram is a popular provider, overall pretty good, but out of us can have higher latency.
• There are some other options, and google gemini can be cheaper.
• Prompting can also help fix STT transcript error.

4.4 TTS

Choose based on:

• How it sounds
• Latency
• Cost
• Language support

Multiple providers: Cartesia, Deepgram, ElevenLabs, Rime
Can still mispronounce, and new models are coming

4.5 Audio Processing

• Mic and automatic gain control, bluetooth can add latency, and some gain control you won’t be able to disable if you need to.
• Echo cancelation, if not done well, bot can hear themselves. WebRTC and mobile have good support.
• Noice cancelation exists, but playing music with it is not very good.
• Echo Encoding Opus is the best.
• Can do server side primary speaker isolation using krisp.
• Voice activity detection.

4.6 Network Transport

Websocket vs WebRTC

• WebRTC can solve a lot of problems Websocket is having.
• Opus handle network better.
• Time stamped.
• Can have analytic from provider.
• Reconnect is handled.
• Echo, noise, gaincontrol.

HTTP

• Is also using TCP so have latency, can have both WebRTC and HTTP on client.

QUIC and MOQ

• New protocol for streaming media, seems promising.

Network routing

• Sending between different region can have longer latency, can do a first close hop to the same region server, then route through private route.

4.7 Turn Detection

Voice activity detection

• Small model, not just volume (silero VAD)

Parameters to adjust:

• Length of pause for count as end
• Length of speech for count as start
• Confidence for classify audio as speech
• Min volume

Can do push to talk, but UX is different, better when long pause happens a lot

Endpoint markers

• “Over” on walkie, but not so easy to make user do it

Context-aware detection

• Small turn detection model
• Us llm to understand context

4.8 Interruption Handling

• The audio pipeline needs to be cancelable to let user interrupt

Some unintended interruptions:

• Noise
• Echo from bot
• Background speech

Maintain context after interruption, so can pickup correctly once back

4.9 Manage Conversation Context

• LLM API providers are sill figuring it out too
• Can modify context between turns

4.10 Function Calling

• Fetch data
• Interact with server & API
• Integration with phone (transfer, DTMF tones)
• Scripts

Reliability - better have eval for function calling

Adding Latency because:

• Function -> run function -> inference again with function result (run twice)
• Function can’t stream
• Some API have higher TTFT when tools are enabled
• Functions can be slow

Handle interruption

• If llm calls a function, need to put request/response in context. If not when interrupted, can get error, or cause in-context-learning not to run funtions

Streaming & function call chunck

• Function needs to handle complete chunk, but maybe can isolate function call chuck with stream chuck

How and where to execute function

• In code, Can be directly
• In code, Can be ambiguated
• Call API from device
• Call API on the cloud

Async function calling, not supported now, need to have it return with a queue.

Parallel & composite functions

• Exciting but adding complexity & inconsistency

4.11 Multimodality

• STOA models are adding more and more Audio and video capabilities

Chapter 5: Using Multiple Models

Fine-tuned model can:

• Embedded knowledge
• Have it’s own response pattern

Start with prompt engineering before fine-tune

Async operations, can pass to reasoning models for complex task
Need to have a function return immediately, and have orchestration to queue and insert result once async is done

Guardrails, can have different models to do guardrails
But model are a lot better than a year ago
Sanity check when touching backend

Inference actions

• More and more new code patterns, such as llm calling another llm as tool

Self-improving system

• Adjust based on user feedback during the call
• VAD self config if interrupt use a lot
• Self adjust response length if user keep interrupting
• What eles?

Chapter 6: Scripting & Instruction Following

It’s hard to pack everything in a prompt, especially when we are adding conversation context

State machine approach, each state have:

• System instruction & tools
• Context
• Ways to exit

Can update & summarize when transition between states (Pipecat flow helps facilitate these)

Chapter 7: Voice AI Eval

Different from unit test, need to have many input, can’t just do yes/no

Failure modes, might not because of llm:

• Latency
• Transcript error
• Names, emails, number got messed up
• Interruption

Run prompt when getting a new model, basic eval is better than no eval
(Coval - a startup focus on this)

Chapter 8: Telephone

Most fast growing applications happens on telephone
It’s easy decision when llm per minute cost is lower than human

Not just ROI:

• Scale, handle high-volume peak
• Can sometimes be better than human

Voice agents are reshaping phone calls, maybe will be AI talking to AI soon?

Some things for phones:

• PSTN (twilio is a PSTN platform)
• SIP
• DTMF (keypress sound for telephone menu)

Warm transfer, where the agent talk during transfer before getting to a human

Chapter 9: RAG and Memory

Can go from basic lookup to complicated semi-structured fetch
Use 80/20 when you have a knowledge base

Memory

• Can save for cross session
• Save & index message metadata graph

Chapter 10: Hosting and Scaling

Voice agent needs to be:

• Long running
• Realtime can’t stall
• Websocket or webRTC

Serverless can not do it
Deploy with docker after prototype
Use kubernetes to scale

Need to think about cold start problem

And setting up start with rule of thumb: L single agent per VM CPU, double the ram on local machine

Use python, gen AI is python-centric

Chapter 11: What’s Coming in 2025

• Latency optimization
• Development in multimodality models
• Audio test & eval
• Context caching
• Voice agent platform providers
• Speech-to-speech model
